After nearly a dozen years of continuous development, the acidizing technology has developed from the analysis on reservoir pollution, the optimization of product system, design of process operation to site all-dimensional acidizing operation capacity. The construction of acidizing experiment is promoted simultaneously with the process design, and by now five fundamental research orientations have been established, including the study on reservoir rocks, the study on physical simulation, the study on acidizing fluid system, the study on the cause analysis of formation pollution and the study on reservoir fluid, with more than 40 sets of specialized supporting instruments configured. We uphold the attitude of technological innovation, and continuously promote the application of "new process, new technology and new material" in the oilfield acidizing.
Relying on the science and technology planning, COSL has completed nearly 25 scientific research and production projects as well as 45 key technological acidizing operations at the Company level and the Division level. Depending on the promotion in the equipment capacity, the Company has completed more than 3800 well-times of acidizing operations during 10 years, opened up several overseas markets, and made contributions to the development of acidizing technology.
Compared with conventional mode of operation, the coiled tubing acidification could facilitate the implementation of uniform acidification technology like fixing points, layering, steering, etc., distribute the acidizing fluid in long well sections, construct repeatedly and in multiple layers, conduct stimulation operations directly without well killing and flow back the reacted acid rapidly by gas lift after acidification so as to avoid the wellhead facilities, completion pipe string as well as the Christmas tree from contacting with the acidizing fluid and prevent corrosion, which is featured with high operation efficiency, cost-saving, convenience and time-saving, safety and reliability, etc.
·Well Type: Horizontal well, highly-deviated well, vertical well with long production section
·Reservoir Lithology: Carbonate rocks or sandstone, with strong heterogeneity
·Dragging Capacity: 20m~40m/section
·Dragging Speed of Coiled Tubing:<25m/min
·This technology is applicable to acid pickling, acidification, organic plug removal and other stimulation operations for carbonate rocks and sandstone reservoirs.
This technique is primarily used in carbonate reservoirs to realize acidizing fluid at fixed points in long horizontal section, and complete the dragging and acidizing operation by coiled tubing in open-hole horizontal well.
Well Name | Length of acidized well section (m) | Mode of completion | Yield before operations (m3/day) | Yield after operations (m3/day) |
X-44H | 164.5 | Open-hole completion (with perforated pipe, but the perforated pipe are not run to place) | Shut down | 579 |
Y-44H | 160.28 | Shut down | 268 | |
Y-29H | 600.2 | Open-hole completion | Shut down | 596 |
X-46H | 599.4 | Shut down | 577 | |
X-57H | 530.2 | Shut down | 655 |
This technique is mainly to remove the paraffin precipitation of oil casing, organic scale of gum asphaltic and other pollutants at the immediate vicinity of wellbore, whose technical core is organic plugging remover system PA-OS3.
This system is featured with high efficiency (with asphaltene dissolution rate of 100%), environmental protection (free from highly toxic substances such as benzene, methylbenzene and xylene), safety (flash point >61℃), etc.
·Paraffin-dissolving rate: 100%
·Asphaltene dissolution rate: 100%
·Surface tension:<28mN/m
·Interfacial tension:<0.8mN/m
·Flash point: >61℃
Remove the plugging at the immediate vicinity of wellbore, wellbore and pipeline caused by paraffin, gum asphaltic, etc.
The supporting acidification has been applied on the site for more than 100 well-times, with obvious oil increment effectiveness.
The viscosity of the clear self-diverting acid made by our Company is highly sensitive to the changes in PH and ionic concentration, and it could block off the high-permeability layer, lower down the reaction rate of acid-carbonate rock, and achieve the results of even acidizing fluid distribution; without polymers, it poses small damage to the formation.
·Temperature resistance: 50~120℃
·Base solution viscosity: <10mPa•s
·Peak viscosity: 50~400 mPa•s
·Mode of gel-breaking: Self-breaking gel
·Gel-breaking viscosity: <5mPa•s
·Corrosion rate at 60℃: 2.67g/(m2•h)
·Capacity to stabilize iron ion: 209mg/mL
·Interfacial tension: 0.35mN/m
·Demulsification efficiency in 20min: >100%
·Carbonate reservoir
The supporting acidification has been applied on the site for more than 100 well-times.
The core additive of system is the gelatinizer, which could tackify the hydrochloric acid system within 25% effectively, and make the acidizing fluid system with better shearing and temperature stability through its tackability, thus lowering down the reaction velocity of acid-carbonate rocks and fluid-loss velocity and reducing the friction of pump injection effectively so as to pump successfully and make acidizing treatment in the deep section of the formation.
·Temperature resistance: 60~140℃
·Viscosity: <30~70mPa•s
·Corrosion rate at 60℃: 1.64g/(m2•h)
·Corrosion rate at 90℃: 2.02g/(m2•h)
·Capacity to stabilize iron ion: 270mg/mL
·Surface tension: 24mN/m
·Demulsification efficiency in 20min: >100%
The gelled acid system is applicable to the acid pickling, acidification and acid fracturing technology in the carbonate rocks (calcareous) reservoir.
This system is mainly used in the carbonate reservoirs of a number of overseas oilfields, and have been applied for more than 100 well-times cumulatively in acidizing operations.
The product PA-VERT is a new additive for stimulation with multiple functions integrating the wetting reversal, unlocking of water lock, inter-solubility, iron stabilization, blistering, cleaning and other features, which has been widely used in acid pickling, acidizing, acid fracturing, unlocking water lock and other working solutions of plug removal for oil-water wells of sandstone and carbonate reservoirs, with the maximum operating temperature up to 160℃.
·Temperature resistance: 160℃
·Surface tension (1%):<25 mN/m
·Interfacial tension (1%):<0.5 mN/m
·Cleanup efficiency: >80%
·Foaming volume: >500%
The product PA-VERT is a new additive for stimulation with multiple functions integrating the wetting reversal, unlocking of water lock, inter-solubility, iron stabilization, blistering, cleaning and other features, which has been widely used in acid pickling, acidizing, acid fracturing, unlocking water lock and other working solutions of plug removal for oil-water wells of sandstone and carbonate reservoirs, with the maximum operating temperature up to 160℃.
The technology has been industrialized and successfully extended to the Middle East, with remarkable effect on oil and gas well production.
PA-SAS is an antiswelling/shrinkage agent of dual-polyquaternary ammonium salt, which not only has better anti-swelling performance, but also has better shrinkage performance as well as better compatibility with acidizing fluid.
·Temperature resistance: 130℃
·Anti-swelling rate (1%): >90%
·Shrinkage rates (1%): >30%
·Resistance to erosion (13 times): >80%
This agent is used in anti-swelling treatment, acidification and acid fracturing operations as an additive.
It has been used as the additive for acidizing for more than 12 well-times; used for 2 well-times in anti-swelling operation and treatment, with average apparent water injectivity index increased from 22m3/(MPa•d) to 30m3/(MPa•d), and has significant efficiency in decompression and augmented injection.
This product refers to Mannixi alkali-type acidizing corrosion inhibitor, which is well compatible with hydrochloric acid, multi-hydrogen acid and fluoboric acid and other working solutions, and could satisfy the requirements of reservoir acidizing operations at 180℃.
·Temperature resistance: 180℃
·Compatibility: Well compatible with acidizing fluid
·Corrosion rate (140℃): <50 g/(m2•h)
·Corrosion rate (160℃):<70 g/(m2•h)
·Corrosion rate (180℃):<80 g/(m2•h)
The ultra-high temperature acidizing corrosion inhibitor is widely used in acidizing and acid fracturing operations at more than 160℃.
It has been applied for more than 10 well-times as an additive of acidizing corrosion inhibitor.
